Product Description

SAGA cutting plotter

Feartures:

1,High force cutting head with 4 wheels

2,Aluminum alloy construction, ABS end caps, welded steel stand

3,Aluminum body structure,sheet metal support,stable use

Applications:

Self-adhesive sticker , label etc.

Maximum thick:0.2mm(depend on material)

Mechanical Parameters:

Model Name	SG-1800II
Maximum sheet size	1800mm
Maximum cutting size	1680mm
Minimum cutting character	About 5mm²
Mechanical resolution	0.02mm
Repeat precision	0.082mm
Maximum linear cutting speed	960mm/s
Maximum cutting force	750g
Cutting control system	DC servo
Motor speed	0-3500 RPM
CPU	64-DSP
Package dimensions	2100mmx400mmx550mm
Acutal dimensions	1960mmx250mmx260mm
GW/NW	68KG/47KG
Software and compatibility
Connectivity	USB/RS-232
Software and compatibility	Dragon Cut,for computer,compatible for Windows7,8,10(USB direct connection to the computer)
	Corel Draw/Illustrator Plug-in(SD direct connection to the computer)
Power and working environment requirments
Power source	100V-240V,50/60Hz
Power	150W
Operation environment	Temperature +5ºC to +35ºC(Fahrenheit 41-95),Humility 30%-75%(Non-condensing)
Stand&Pocket	Included

This parameter is subject to change without prior notice.The company reserves the right of final interpretation.
Automatic Vinyl Die Cutter (SG-1800II)
